Elsema FMR15102240E 151MHz 2-Channel Receiver – Enclosed
The Elsema FMR15102240E is a genuine Elsema two-channel receiver designed for long-range wireless control in rural, agricultural, commercial and industrial applications. It operates directly from a 110–240VAC mains supply and is supplied in an IP66-rated weather-resistant enclosure.
Two independent voltage-free relay outputs allow separate equipment or functions to be controlled from the same receiver. Applications include pumps, irrigation equipment, gates, lighting, alarms, machinery and basic telemetry systems.
What’s Included:
- 1 × Brand New Genuine FMR15102240 Receiver
- 1 x Quickmount
- 1 x IP66-rated weatherproof enclosure
- Step-by-step Wiring Programming Instructions
Note: This product is for the Australian market. A modified frequency is required for New Zealand, US and Canadian Market (please contact us for more information). This item is not available for sale in other countries due to frequency regulations.
Key Features:
- Two independent relay outputs – Control two devices or functions
- 110–240VAC mains supply – No separate low-voltage power supply required
- IP66-rated enclosure – Suitable for appropriately installed outdoor applications
- Long-range 151MHz operation – Up to 5km line of sight with the appropriate transmitter and antenna
- Eight selectable frequencies – Helps reduce interference between nearby systems
- Flexible relay modes – Momentary, latching, delayed-off and security latching
- 12-way DIP-switch coding – Simple matching with compatible FMT151 transmitters
- Unlimited compatible transmitters – No individual remote-memory limit
- Voltage-free relay outputs – Suitable for a wide range of control applications
Compatible with:
Ideal Applications:
- Farm Gates
- Water Pumps
- Quarry equipment
- Industrial Roller Doors
- Remote switching
- Long Driveway access
- Mines and Work sites
- Livestock property access
- Wireless machinery control
- Rural access systems.
Connection Diagram for FMR15102240R
Technical Specifications:
| Frequency | 151.6MHz (8 selectable frequencies) Australian Market |
| Code Type | Dipswitch |
| Body Type | Receiver |
| Number of Channels | 2 |
| Enclosure | IP66-rated weatherproof enclosure |
| Size | 130 x 70 x 37mm |
| Mounting Hole Size | 3.97mm |
| Power Supply | 110 – 240Volts AC Mains |
| Current Consumption | 18mA at 240V AC |
| Connection | Supply & Output – pluggable type terminal blocks |
| Output | Change over relay output, rated at 16 Amps of resistive load and up to 8 Amps of inductive load |
| Memory Capacity | Unlimited |
| Range | Up to 5km when used with correct transmitter and antenna |
| Warranty | 12 months Manufacturers Warranty |
Downloads:
Frequently Asked Questions:
Which transmitters work with the FMR15102240E?
The receiver is compatible with Australian-frequency Elsema FMT151 transmitters, including the FMT15101E, FMT15108E, FMT15104H and FMT15108H.
Can this receiver achieve a 5km operating range?
Up to 5km line-of-sight range may be possible when the receiver is used with an appropriate long-range FMT151 transmitter and correctly installed ANT151M antenna. Buildings, terrain, electrical interference, antenna placement and the selected transmitter can reduce the achievable range.
Does it require a separate power supply?
No. The FMR15102240E accepts a 110–240VAC mains supply. Installation must be completed by a suitably qualified person where required.
