Elsema 151Mhz FMR15101 Receiver

Elsema 151Mhz FMR15101 Receiver

$99.95
$99.95
Sale Sold out
Shipping calculated at checkout.

This is a popular item that is regularly replenished from our Australian supplier. It is always available to purchase, even if our on-hand warehouse stock is low. If you need this item urgently, please contact us for current stock levels.

FMR15101 - Elsema 151Mhz Single Channel Receiver with up to 5km Range

The Elsema FMR15101 151MHz Single Channel Receiver delivers ultra long-range wireless control up to 5km line-of-sight when paired with FMT151 transmitters, making it ideal for remote switching and automation in farms, industrial sites and pump control applications. With selectable output modes, 8 FM frequency channels and wide voltage input (12–24V AC/DC), this receiver offers simple, reliable operation for single-function control systems.

What’s Included:

  • 1 × Brand New Genuine FMR15101 Receiver
  • 1 x Quick Mount
  • Step-by-step Wiring Programming Instructions

Note:  This product is for the Australian market.  A modified frequency is required for New Zealand, US and Canadian Market (please contact us for more information).  This item is not available for sale in other countries due to frequency regulations.

Key Features:

  • Long Range Performance: Operates up to 5km with matching Elsema FMT transmitter.
  • Single Channel Output: Ideal for controlling one device or circuit
  • Adjustable Output Modes: Momentary, Latching or Delayed-Off operation
  • Wide Voltage Range: 12 – 24V AC/DC supply for installation flexibility
  • Unlimited Remote Storage: Supports unlimited compatible transmitters
  • Australian Compliance: Meets local frequency regulations for Australia*

Compatible with:

Remotes:

  • FMT15101E
  • FMT15108E
  • FMT15104H (Max 800m Range)
  • FMT15108H (Max 800m Range)

Ideal Applications:

  • Pump Control
  • Long distance panic button
  • On/Off applications in agricultural devices
  • Security alarm
  • Basic Telemetry eg. Water level indication

Connection Diagram:

FMR15101 Connection Diagram

Technical Specifications:

Frequency 151.6MHz (8 selectable frequencies) Australian Market
Code Type Dipswitch
Body Type Receiver
Number of Channels 1
Enclosure Nil
Size 95 x 70 x 30mm
Mounting Hole Size 3.97mm
Power Supply 12-24 Volts AC or DC
Current Consumption  24mA Standby at 12 VDC

57mA when relay “ON” at 12VDC
Outputs  One Change over relay outputs, rated at 8Amps 240VAC
Memory Capacity Unlimited
Range Up to 5km when used with correct transmitter and antenna
Warranty 12 months Manufacturers Warranty
