Automatic Technology FHCRX2v2 Receiver

Automatic Technology FHCRX2v2 Receiver

$117.95
$117.95
Sale Sold out
Shipping calculated at checkout.

FHCRX2v2 - Genuine ATA Receiver for TrioCode and TriTran 128 Bits Only

The FHCRX2v2 Genuine ATA Receiver is a dual-channel, 128-bit receiver designed exclusively for TrioCode & TriTran 128-bit remotes, including PTX6v1 and TB7. With support for up to 250 remotes, universal relay output modes, and easy integration into new or existing systems, it’s an ideal upgrade for gates, garage doors, and automation control where enhanced security is required.

What’s Included:

  • 1 × Brand New Genuine FHCRX2v2 Receiver
  • Step-by-step Wiring Programming Instructions

Key Features:

  • Two Channel Output: Control up to two separate devices from one receiver
  • Versatile Integration: Connects to compatible non-ATA devices for seamless remote operation
  • 2 Relays: provide normally open or normally closed control to control virtually any device.
  • Large Remote Memory:  Up to 250 remotes availability
  • Simple Setup – Easy installation and programming for fast operation
  • Reliable Performance – Built to ATA”s high standards for consistent, long-lasting use.
  • Three Relay settings: Pulse Mode; Hold Mode or Timer Mode

Note:  Timer mode requires an ATA Programmer

Compatible with:

Current Genuine Remotes:

  • ATA PTX6v1
  • B&D TB7

Discontinued Genuine Remotes:

  • ATA PTX2v2
  • ATA PTX5v2
  • B&D TB5 (Grey Buttons)
  • B&D TB6

Note:  This receiver is not compatible with the 64Bit TrioCode and Tritran remotes or the ATA Securacode PTX4 remote.

Technical Specifications:

Frequency 433.47, 433.92 & 434.37Mhz
Code Type 128 Bit Rolling Code
Body Type Receiver
Number of Channels 2 Channels (Normally Open or Normally Closed)
Case Colour Grey
Size 69 x 36 x 14mm
Power Supply 12-24 AC/DC
Relay Contact Rating  1 amp @ 24 volts DC
Memory Capacity 250 Remotes
Antenna Connection Optional Coaxial Antenna Available
Range Up to 40 metres
