Elsema Multicode MCR915016SS – 16 Ch Receiver with Ope...
$144.95
Out of stock
For pricing and availability, please CONTACT US to request a quote
The Elsema Multicode MCR915016SS – 16 Ch Receiver with Open Collector Output is a premium quality Receivers from the trusted brand Elsema, designed for excellent performance and reliability. This item is currently and ready for immediate dispatch from our Australian warehouse. When you order from Retro Remotes, you’re choosing an Australian-owned business that offers competitive pricing and free, fast shipping to anywhere in Australia. For easy reference when matching parts, the product SKU is 58934. Secure your Elsema Multicode MCR915016SS – 16 Ch Receiver with Open Collector Output today with confidence!
Features:
- Frequency Hopping Technology: Operates between 915MHz and 928MHz, providing exceptional resistance to interference and jamming.
- Sixteen Channels: Allows simultaneous reception across all channels, enabling seamless control of multiple devices.
- Dual Digital Coding:
- 12-Way Dipswitch: Simple programming by matching transmitter and receiver settings.
- Encrypted Coding: Offers over 16 million unique codes for high-security applications.
- Open Collector Outputs: Each channel can switch up to 40VDC and 120mA, providing versatile low-current control options.
- Selectable Output Modes:
- Momentary: Outputs remain active while the transmitter button is pressed.
- Latching: Outputs toggle on/off with each button press.
- Security Latching: Outputs stay active until power to the receiver is interrupted.
- Wide Voltage Range: Operates on 12–24V DC, making it compatible with various power supplies.
- LED Indicators: On-board red LED provides visual feedback for signal reception.
- Expandable System: Supports unlimited transmitter connections, ensuring scalability for growing needs.
Includes:
- 1 x Genuine Elsema MCR915016SS Receiver
- Programming Instructions
Applications:
- Industrial Automation: Ideal for controlling cranes, winches, and cement truck operations.
- Equipment and Machinery Control: Ensures reliable operation in heavy-duty environments.
- Security Systems: Perfect for alarms, gates, and advanced access control.
- Home Automation: Use it to control gates, garden lights, swimming pools, and more.
Note: This item cannot be sold in the following countries due to Frequency Band licences:
- United Kingdom, Netherlands, Germany and Singapore – No licence available
- New Zealand – MCT series must be modified to operate between 921 to 929 MHz (Please Contact Us for Special Order with Elsema)
- US & Canada – Please Contact Us for Special Order with Elsema – Modifications to Frequency Hopping and Radiated Power
The Elsema MCR915016SS is an advanced 16-channel receiver designed to meet the demands of industrial and commercial automation. Featuring open collector outputs and dual digital coding technology, it delivers exceptional performance, flexibility, and security for controlling a wide range of devices. Operating on the 915MHz frequency band with Frequency Hopping Spread Spectrum (FHSS) technology, the MCR915016SS ensures interference-free operation, even in environments with multiple devices.
